CYRIN DC & AC Thermistor PTC for Heating from 80 degree C to 310 degree C in widely application
Product Features
-
PTC means positive temperature coefficiency, the PTC thermistors works rely on it's self-regulating effect as it's unique property
-
In heating applications, PTC offers long term stability heating power and max temperature is according to its surface temperature, unlike the traditional resistance coil heating element, PTC operates more efficiently and safely.
-
RoHS and UL approval
-
Ts can be from 80 degree C to 310 degree C.
Product Available Design
- Rated Voltage: 12V,24V,48V, 100-120V, 200-240V.
- Curie Temperature: 80-295 deg.C
- Resistance Range: 1-3.0K ohm
- Types: Rectangle, Circle,Rings
| Model No. | Dimension | Ts | Inrush | Voltage | Resistance (Ω) Resistant | Certificate |
| (mm) | (℃) | (A) | (V) |
| JK080F3A1B | 24*15*2.5 | 115 | ≤3 | 100-240 | 200-2000 | UL/CUL |
| JK135F2C4B | 25*9*2.1 | 170 | ≤3 |
| JK185F3A1B | 24*15*2.5 | 215 | ≤3 |
| JK215F3B6B | 35*6*2.5 | 240 | ≤3 |
| JK235F2D2B | 23*13*2.1 | 260 | ≤4 |
| JK120F6A8A | 24*10*2.0 | 130 | ≤4 | 110-240 |
| JK140F2A2A | 24*13*2.1 | 160 | ≤4 |
| JK185F6A8A | 24*10*2.0 | 200 | ≤4 |
| JK190F3A1A | 24*15*2.5 | 200 | ≤4 |
| JK190F2A2A | 24*13*2.1 | 200 | ≤4 |
| JK220F3A1A | 24*15*2.5 | 235 | ≤4 |
| JK225F6A8A | 24*10*2.0 | 240 | ≤4 |
| JK240F2A5A | 24*8*2.1 | 250 | ≤4 |
| JK240F3A8A | 24*10*2.5 | 250 | ≤4 |
| JK240F2A1A | 24*15*2.1 | 250 | ≤4 |
| JK250F6A8A | 24*10*2.0 | 270 | ≤4 |
| JK210F3B2A | 35*13*2.5 | 220 | ≤4 | UL |
| JK180F3B2A | 35*13*2.5 | 190 | ≤4 |
| JK245F3A1B | 24*15*2.5 | 270 | ≤4 |
| JK245F8B2A | 35*13*2.3 | 270 | ≤4 |
| JK180F8B2A | 35*13*2.3 | 190 | ≤4 |
| JK240F6B2A | 35*13*2.0 | 260 | ≤4 |
| JK210F6B2A | 35*13*2.0 | 230 | ≤4 |
| JK190F6B2A | 35*13*2.0 | 200 | ≤4 |
| JK150F6B2A | 35*13*2.0 | 170 | ≤4 |
| JK245F8B8A | 35*10*2.3 | 270 | ≤4 |
| JK245F3B9A | 35*10*2.5 | 270 | ≤4 |
| JK190F2J8A | 33*10*2.1 | 200 | ≤4 |
| JK245F8K2A | 30*13*2.3 | 270 | ≤4 |
| JK225F8K2A | 30*13*2.3 | 245 | ≤4 | 110－240 | 200-2000 | UL |
| JK245F3B5A | 35*8*2.5 | 270 | ≤4 |
| JK210F5B6A | 35*6*2.7 | 220 | ≤4 |
| JK180F5B6A | 35*6*2.7 | 190 | ≤4 |
| JK150F5B6A | 35*6*2.7 | 160 | ≤4 |
| JK245F3B6A | 35*6*2.5 | 270 | ≤4 |
| JK245F8B7A | 35*6*2.3 | 270 | ≤4 |
| JK180F8B6A | 35*6*2.3 | 190 | ≤4 |
| JK240F6B6A | 35*6*2.0 | 260 | ≤4 |
| JK210F6B6A | 35*6*2.0 | 230 | ≤4 |
| JK190F6B6A | 35*6*2.0 | 200 | ≤4 |
| JK150F6B6A | 35*6*2.0 | 170 | ≤4 |
| JK245F3A2A | 24*13*2.5 | 270 | ≤4 |
| JK245F8A2A | 24*13*2.3 | 270 | ≤4 |
| JK245F3A8A | 24*10*2.5 | 270 | ≤4 |
| JK245F6A0A | 24*4*2.0 | 260 | ≤4 |
| JK170Y43A | ø12*2.5 | 190 | ≤4 |
| JK120Y43A | ø12*2.5 | 140 | ≤4 |
| JK190Y53A | ø8.5*2.5 | 210 | ≤4 |
| JK150Y53A | ø8.5*2.5 | 170 | ≤4 |
| JK110Y53A | ø8.5*2.5 | 130 | ≤4 |
| JK150F9I7A | 5*4*1.6 | 160 | ≤4 | 400-2000 |
| JK170F6B6A | 35*6*2.0 | 180±15％ | 12 | 220－240 | 200-2000 | TUV |
| JK200F6A8A | 24*10*2.0 | 210±10％ | 12 |
| JK215F6B6A | 35*6*2.0 | 225±10％ | 12
|
PTC Thermistor Show
Product Applications
PTC thermistor heater can be assemble into a heating element with heating sink, heating plates and heating tubes for kinds of applications.
•Fan heating element for ceramic heater fan, hair dryer, hand dryer, clothes dryer, dish dryer etc.
•Heating plates for coffee makers, steam irons, cooking devices, facial sauna, humidifier etc.
•Tube heating elements for hot melting guns ,curing irons, wax-warmer, glue gun, dehumidifier etc.
•Other shapes of heating element can be used for mosquito repellent, liquid warmer, control devices etc.
- The big size PTC heating element can be design for the industry air conditioner, drinking heaing machine, trains air conditioners etc.
PTC Thermistor Package
FAQ
What is your minimum order quantity?
At least 1000pcs for each item.
What is the delivery period?
About 20-25days, it is up to your order quantity.
What is your payment term?
T/T(30% before production and 70% before shipment),L/C,D/A, D/P, T/T, Western Union, MoneyGram, OA
Can you send free samples?
We can send free samples.
What is your shipping ways?
For sample we usually send by DHL, FEDEX, UPS, THT, EMS(taking 5-7business days). For mass product we are shipping by sea or by air.
